The NSOPA084 provide industry-leading performance over TL084 devices. These devices provide outstanding value for cost-sensitive applications, with features including low offset (0.5mV, typical), high slew rate (30V/μs), and common-mode input to the positive supply. High ESD (2kV, HBM), integrated EMI and RF filters, and operation across the full –40°C to 125°C enable the NSOPA084 devices to be used in the most rugged and demanding applications.
• High slew rate: 30 V/μs typ
• Unity-gain bandwidth: 6 MHz
• Low offset voltage: 0.5 mV typ
• Low offset voltage drift: 1 μv/°c typ
• Low power consumption: 600 μA/ch typ
• High common-mode rejection (CMRR): 109 dB
• Wide common-mode and differential voltage ranges
• Common-mode input voltage range includes V+
• Low input bias and offset currents
• Low noise: en= 15 nV/ Hz (typ) at 10 kHz
• Output short-circuit protection
• Low total harmonic distortion: -105 dB typ
• Pulse friendly/comparator input
• Amplifier can be used in open-loop or as comparator
• Wide supply voltage: ±2.25 V to ±18 V, 4.5 V to 36 V
• RoHS and REACH Compliance
• General-purpose amplification
• Power control and monitoring
• Active filters
• Industrial/process control
• Data acquisition
>
>
>
>
>
>
>
